| Type |
ATX12V |
| Maximum Power |
650 W |
| Fans |
120mm Hydraulic Bearing (HYB)Fan |
| PFC |
Active |
| Main Connector |
20+4Pin |
| PCI-Express Connector |
4 x 6+2-Pin |
| SATA Power Connector |
6 |
| Max PSU Length |
150 mm |
| Energy-Efficient |
80 PLUS GOLD Certified |
| Protection |
OPP/UVP/OVP/SCP/OCP |
| Input Voltage |
100-240 Vac (full range) |
| Input Frequency Range |
50/60 Hz |
| Input Current |
9-4A |
| MTBF |
>100,000 Hours |
| Approvals |
CE/CCC/BSMI/KCC/EAC/UL/TUV/RCM/FCC |
| Connectors |
ATX/MB 20+4 Pin x 1
CPU/EPS 4+4 Pin x 1
PCI-e 6+2 Pin x 4
SATA x 6
4 Pin Peripheral x 3
4 Pin Floppy x 1 |
| Cable Spec |
Black Flat Cables |
