Brand

Intel

Processors Type

Desktop

Series

Core i7 14th Gen

Name

Core i7-14700K

Model

BX8071514700K

CPU Socket Type

LGA 1700

Core Name

Raptor Lake

# of Cores

20-Core (8P+12E)

# of Threads

28-Threads

Operating Frequency

Performance-core Base Frequency: 3.4 GHz

Efficient-core Base Frequency: 2.5 GHz

Max Turbo Frequency

Intel Turbo Boost Max Technology 3.0 Frequency: Up to 5.6 GHz

P-core Max Turbo Frequency: Up to 5.5 GHz

E-core Max Turbo Frequency: Up to 4.3 GHz

L2 Cache

28MB

L3 Cache

33MB

Manufacturing Tech

Intel 7

64-Bit Support

Yes

Hyper-Threading Support

Yes

Memory Types

DDR4 3200 / DDR5 5600

Memory Channel

2

Max Memory Size

192 GB

ECC Memory

Supported

Max Memory Bandwidth

89.6 GB/s

Virtualization Technology Support

Yes

Integrated Graphics

Intel UHD Graphics 770

Graphics Base Frequency

300 MHz

Graphics Max Dynamic Frequency

1.6 GHz

Scalability

1S Only

PCI Express Revision

5.0 / 4.0

PCI Express Configurations

Up to 1x16+4, 2x8+4

Max Number of PCI Express Lanes

20

Thermal Design Power

125W

Max Turbo Power

253W

Cooling Device

Cooling device not included - Processor Only

Compatible Desktop Chipsets

Intel H610 / Intel H670 / Intel B660 / Intel Q670 / Intel W680 / Intel Z690 / Intel H770 / Intel B760 / Intel Z790

* BIOS update may be required when used with some old chipset motherboard

Operating System Supported

Linux / Windows 10 (22H2, 21H2) / Windows 11 (22H2, 21H2)

Advanced Technologies

Intel Gaussian & Neural Accelerator: 3.0

Intel Thread Director

Intel Deep Learning Boost (Intel DL Boost) on CPU

Intel Speed Shift Technology

Intel Turbo Boost Max Technology 3.0

Intel Turbo Boost Technology: 2.0

Intel Hyper-Threading Technology

Intel 64

Instruction Set: 64-bit

Instruction Set Extensions: Intel SSE4.1, Intel SSE4.2, Intel AVX2

Idle States

Enhanced Intel SpeedStep Technology

Thermal Monitoring Technologies

Intel Volume Management Device (VMD)

Security & Reliability

Intel Standard Manageability (ISM)

Intel Control-Flow Enforcement Technology

Intel AES New Instructions

Secure Key

Intel OS Guard

Execute Disable Bit

Intel Boot Guard

Mode-based Execute Control (MBEC)

Intel Virtualization Technology (VT-x)

Intel Virtualization Technology for Directed I/O (VT-d)

Intel VT-x with Extended Page Tables (EPT)
